H-1746.7

Zeitfuchs® Cross-Arm Viscometer and Holder

These models are used to determine kinematic viscosity of liquid asphalts, road oils and distillation residues of liquid asphalts at 140°F (60°C) and of asphalt cements at 275°F (135°C), requiring a charge of only 1 to 3ml. They are easily filled and cleaned while immersed in a temperature bath and need not be removed. The viscometers require a liquid depth of 9″ (229mm). Includes round metal holder for 2″ (51mm) dia. hole and certificate of calibration.

Category:

Description

Supports the following standards: ASTM D2170, ASTM D2171, AASHTO T201, ISO 3105

These models are used to determine kinematic viscosity of liquid asphalts, road oils and distillation residues of liquid asphalts at 140°F (60°C) and of asphalt cements at 275°F (135°C), requiring a charge of only 1 to 3ml. They are easily filled and cleaned while immersed in a temperature bath and need not be removed. The viscometers require a liquid depth of 9″ (229mm). Includes round metal holder for 2″ (51mm) dia. hole and certificate of calibration.

Products

Part Number & Name
H-1746.1
Zeitfuchs® Cross-Arm Viscometer and Holder: Size 1: 0.003 Approx. Constant Cs/Sec., 0.6 to 3 Centistokes
H-1746.2
Zeitfuchs® Cross-Arm Viscometer and Holder: Size 2: 0.01 Approx. Constant Cs/Sec., 2 to 10 Centistokes
H-1746.3
Zeitfuchs® Cross-Arm Viscometer and Holder: Size 3: 0.03 Approx. Constant Cs/Sec., 6 to 30 Centistokes
H-1746.4
Zeitfuchs® Cross-Arm Viscometer and Holder: Size 4: 0.1 Approx. Constant Cs/Sec., 20 to 100 Centistokes
H-1746.5
Zeitfuchs® Cross-Arm Viscometer and Holder: Size 5: 0.3 Approx. Constant Cs/Sec., 60 to 300 Centistokes
H-1746.6
Zeitfuchs® Cross-Arm Viscometer and Holder: Size 6: 1.0 Approx. Constant Cs/Sec., 200 to 1,000 Centistokes
H-1746.7
Zeitfuchs® Cross-Arm Viscometer and Holder: Size 7: 3.0 Approx. Constant Cs/Sec., 600 to 3,000 Centistokes
H-1746.8
Zeitfuchs® Cross-Arm Viscometer and Holder: Size 8: 10 Approx. Constant Cs/Sec., 2,000 to 10,000 Centistokes
H-1746.9
Zeitfuchs® Cross-Arm Viscometer and Holder: Size 9: 30 Approx. Constant Cs/Sec., 6,000 to 30,000 Centistokes
H-1746.10
Zeitfuchs® Cross-Arm Viscometer and Holder: Size 10: 100 Approx. Constant Cs/Sec., 20,000 to 100,000 Centistokes

Standards

Standards
ASTM D2170
ASTM D2171
AASHTO T201
ISO 3105
